05-23 Tacoma Mid Travel Suspension Kit, Stage 3A – Ride Shocks

SKU: KIT-3000-0152
Free Shipping On Orders Over $150

The front & rear shocks in this kit are ideal for a 2016-2023 3rd Gen Toyota Tacoma that has little to no added weight from accessories. This complete suspension kit featuring the new Ride Shocks features everything necessary to lift your Tacoma up to 2.5″ and provides the ultimate ride quality for on-road and off-road driving. 2.5 Ride Shocks with compression adjusters will be custom tuned to fit your vehicles weight and intended use.

-Front Coilovers: Ride Shocks 2.5 Coilover Remote Reservoir with DPA Adjusters (2100-2750LB Front Wt Range)
-Sway bar relocation brackets included with shocks
-Front Tubular UCA: AccuTune Offroad
-Rear Shocks: Ride Shocks 2.5 Smoothie Remote Reservoir with DPA Adjusters (1750-2350LB Rear Wt Range)
-Rear Springs: Icon Mini Pack
-Rear U-Bolt Flip: AccuTune Offroad
-Rear Bump Stop: AccuTune Offroad

Front Coilovers:
2016-2023 Tacoma | 0-2” Lift
2005-2015 Tacoma | 0-3” Lift

2 in stock

$5,427.75

-

*Please Note. Leaf springs are received from the manufacturer without packaging and are shipped to you without packaging. The paint finish will be scratched by the freight carriers during the shipping process. The leaf springs can be spray painted to cover any bare metal exposed during the shipping/handling process.
California Prop 65 Warning
Visit www.p65warnings.ca.gov for more details
  • Features
  • Specifications

Features

AccuTune Offroad Premium Support

At AccuTune Offroad we are shock specialists with real world experience to help you select the right shocks for your ride. After the sale we offer tuning support and one free re-valve so you can get the most out of your shocks. Take your ride to the next level with Ride Shocks shocks from AccuTune Offroad.

Ride Quality

Drawing on more than 15 years of experience fine-tuning top name-brand shocks, Ride Shocks’ team of engineers set out to create the market’s premier OEM fit shock at a cost that competes with our rivals. What distinguishes Ride Shocks is our unwavering commitment to providing exceptional performance without compromising affordability.

Our engineers have seamlessly integrated their extensive knowledge and background into every aspect of our shocks, ensuring that you not only get a superior riding experience but also an OEM fit that surpasses industry standards. Choose Ride Shocks for precision, reliability, and a smoother ride that complements the specific characteristics of your vehicle.

AccuTune Offroad Upper Control Arms

After market upper control arms are needed when lifting your Tacoma over 2” or when using extended travel coilovers. AccuTune Offroad Upper Control Arm is designed to fit larger tires and longer shocks, while maintaining proper alignment. Tubular steel design looks great with high quality powder coat finish. FK Rod ends are sealed to keep dirt and debris from premature wear and noise. Heim joints come pre-set and ready to install.

Piston Assembly

At the core of every shock lies its main piston valving. Ride Shocks has introduced a groundbreaking (patent pending) piston design that efficiently directs a significant volume of oil through a network of ports, leading to either the compression or rebound side shim stack. This stack, comprised of progressively smaller shims, offers a unique capability to finely control the shock's up and down movement. With the flexibility to adjust the number of shims, we can achieve a meticulously balanced ride. At Ride Shocks, we take it a step further by customizing the valving of each shock to harmonize with the specific vehicle weight, ensuring an optimal blend of bump handling and a plush ride experience.

DPA Adjusters

DPA stands for Dual Piston Adjuster. With the turn of a knob, you can independently adjust your shocks HIGH and LOW speed compression levels. From the factory, your adjusters will both be fully decreased (open). Increasing (closing) the LOW speed will allow you to stiffen the ride of your suspension and make it less active during low speed (shaft speed/not vehicle speed) movements. This comes in handy when the suspension feels too bouncy over gradual rolling bumps. Increasing the HIGH speed will allow you to dial in your ride when shooting through rough washboard terrain and can also come in handy when adding weight to your vehicle.

AccuTune Offroad U-Bolt Flip & Bump Stop Kit

The AccuTune Offroad U-Bolt Flip Kit is designed to allow for maximum suspension travel on the rear of a 2005+ Toyota Tacoma. The u-bolt flip design will provide better ground clearance for off-road use and the specially designed bump stops will improve ride quality.

Specifications

Specifications

  • Product Front Coilovers: 525412389
  • Product Spring Rate: 3.0" x 14" x 600LB
  • Product Front Weight Range: 2100-2750 LB
  • Front Compressed Length: 16.60"
  • Front Extended Length: 22.60"
  • Front Travel: 6.00"
  • Product Front Upper Control Arms: AOR-2000-0025
  • Product Rear Shocks: 525412789
  • Product Rear Weight Range: 1840-2160 LB
  • Product Rear Springs: ICON-51100
  • Rear Compressed Length: 15.73"
  • Rear Extended Length: 25.61"
  • Rear Travel: 9.88"
  • Product U-Bolt Flip Kit: AOR-2000-0024-175
